Drilling Steel

Strong, durable steel forms the foundations of numerous essential industries. However, before steel can be effectively utilised for a range of applications, it must be transformed into functional steel components. This process often requires techniques like precise steel drilling services.

Steel drilling allows for the creation of intricate components, complex and contoured designs, holes for fasteners, and other key elements. These components play vital roles in manufacturing, equipment production, construction, mining, and many other sectors, from small scale projects to large-scale industrial endeavours.

Find Out More

Services

Application - Flats, angles, box section, columns, beams & channels.
Minimum Profile Width - 1017mm
Maximum Profile Height - 500mm
Maximum Profile Length - 18,300mm
Drilled Hole Size - 8mm to 40mm
Punch Hole Size - 26mm or 30mm length, widths from 12mm to 22mm


Our drilling & punching lines operate 24 hours a day, allowing us to provide the quickest turnaround for your material. We can drill all our structural steel sections and with a choice of tooling options available we can produce and deliver the finished steel section that you need.

What are the different drilling techniques?

The process of drilling stainless steel requires the use of a few different techniques to achieve optimal results and finishes. The most widely used methods of steel drilling include:

  • Core drilling. This type of steel drilling utilises hollow, cylindrical drill bits to create holes with larger diameters. It is frequently used to create openings in steel for fasteners, conduits, and pipes.
  • Twist drilling. This widely used drilling technique makes use of a rotating drill bit fitted with helical flutes. This specialised bit effectively removes steel materials and is used to create a variety of hole sizes in steels of varying thicknesses.
  • Trepanning. Trepanning is a similar approach to core steel drilling but produces thin annuli and retains solid cores when cutting holes in steel. This approach enables drillers to create large holes in steel while minimising material wastage.
  • Laser drilling. This technique uses a targeted laser tool to cut clean and precise holes in steel sheets, plates and components.
  • Steel gun drilling. Gun drilling is the optimal approach for cutting deep holes in steel. It utilises a unique, single-flute drill bit and pressurised coolants to create precise, straight holes.



What equipment and technology are required for drilling through steel?

Steel drilling requires the use of specialised equipment, and modern processes also use advanced technology to improve the accuracy and efficiency of drilling.

The equipment needed for drilling stainless steel and other steel types includes drill presses, which provide optimal control for drilling, and a range of drill bits. These may include core drill bits, twist drill bits, and bits which are specially engineered to cut various hole sizes and grades of steel.

Professionals also use cutting fluids like coolants and lubricants during the process. These fluids reduce heat and damage to the steel caused by friction. They also enhance the performance of steel drill equipment and extend the lifespans of drill bits.

Computer Numerical Control (CNC) machines and high-speed drilling machines are also utilised to automate the drilling process. They are designed to precisely cut simple and complex patterns and holes and are well suited to large-scale production needs.

The incorporation of sophisticated technologies into steel drilling improves the speed and precision of drilling work. It also helps to minimise the margin of error involved and reduce material waste, making for a more efficient and cost-effective process.



What are the applications of drilled steel components?

Drilled steel components are widely used across a range of industries and sectors. The most widespread applications of drilling through steel include:

  • Construction. Drilled steel plates, beams and columns are often used to create robust and durable connections in the construction of bridges, buildings, and other key pieces of infrastructure. Precisely drilled holes enable construction experts to accurately align and secure fastenings for enhanced strength.
  • Energy production. Energy infrastructure like oil rigs, oil and gas pipelines, and wind turbines are crafted from drilled steel components to provide them with ongoing structural integrity.
  • Manufacturing. Numerous manufactured equipment, vehicles and machines are assembled and reinforced using drilled steel.
  • Electronic infrastructure. Drilled steel enclosures and chassis are used to mount and protect sensitive electronic systems, maximising their lifespans and performance.



Why choose SPS for steel drilling services?

SPS offers expert steel drilling services which combine quality equipment with the latest tools and technologies. We specialise in drilling a wide range of steel products, including drilling through stainless steel, and can assist with projects of all scopes and sizes to meet your needs.

Our steel drilling and punching lines operate 24 hours a day, ensuring that we can provide you with rapid turnaround times and results which meet and exceed the strictest industry quality and performance standards. Our structural steel sections can be drilled with a variety of tool options to produce and deliver finished steel sections according to your exact specifications.



Get the best results with drilling steel

Drilled steel components are vital materials for a diverse range of industries, from construction and manufacturing to energy, and agricultural. Our drill stainless steel services combine our wealth of experience in the steel industry with leading tools and technologies, enabling us to produce high-quality results that will facilitate the successful completion of your projects.

Contact our team to discover more about our steel drilling services. Find out how to drill stainless steel and how we can meet your project’s needs.
